Visio Diagram – Network Architecture


A user-editable Visio diagram outlining the planned logical switch architecture.

Category: Tags: , ,


A user-editable Visio diagram will be provided to outline the logical network architecture of the switches included with your order. The diagram will show switch names, links between switches, and IP address assignment. Customer will need to provide information related to the planned physical network architecture to ensure accuracy of the documentation.
